Variable Frequency Drives control the speed and torque of AC motors by varying the frequency and voltage supplied to them. Common applications include HVAC fans and pumps, water and wastewater treatment systems, food processing conveyors, irrigation systems, manufacturing equipment, and industrial automation. VFDs also deliver measurable energy savings by matching motor speed to actual load demand rather than running at full speed continuously.

Low voltage VFDs typically operate at 240V or 480V and cover power ranges from 0.5HP to 800HP, suitable for most general industrial and HVAC applications. Medium voltage VFDs operate at 4kV to 35kV and handle 300HP to 12,000HP, designed for large motors in mining, oil and gas, water treatment, and heavy industry where standard low voltage solutions are insufficient.

IEEE 519 compliance means a VFD limits harmonic distortion injected into the power system to acceptable levels defined by the standard — 5% Total Demand Distortion (TDDi) and 8% Total Harmonic Voltage Distortion (THDv). This is critical for municipal, utility, and mission-critical facilities where harmonic pollution can damage sensitive equipment or violate utility interconnection requirements.

For washdown environments such as food processing plants or chemical facilities, select a drive with a UL Type 4X (IP66) enclosure, such as the Benshaw SW Series Washdown Drives. This rating protects against high-pressure water jets, corrosive substances, and dust ingress. Standard NEMA 1 or IP20 open chassis drives are not suitable for these harsh conditions and should only be used in clean, dry environments.

Several ValuAdd VFD models, including the H2 Series, GM2 Series, and SW Series, accept single-phase input power, though derating is required. This means the drive's output capacity must be reduced from its rated value to compensate for the unbalanced input. It is important to consult the product specifications and technical support team to ensure proper sizing when operating from single-phase supply.

ValuAdd's VFD lineup supports a wide range of industrial communication protocols to facilitate system integration. These include Modbus-RTU, Modbus TCP, Ethernet IP, Profibus-DP, BACnet, and Metasys-N2. Protocol availability varies by model — for example, the H2 Series supports BACnet and Metasys-N2 for HVAC building automation, while the S Series supports Ethernet IP and Profibus-DP for advanced industrial automation networks.
